Sencan Automation Machinery Co., Ltd. is a professional manufacturer of non-standard customized machine, integrating design, manufacturing and sales. As the earliest non-PVC infusion cap assembly machine supplier in China, Sencan has been striving for innovation, focusing on customer needs and creating value for more than 10 years. Sencan continues to focus on the needs of users, research consumables overall assembly solution, has developed a number of special equipment. Sencan has a professional assembly after-sales service team to create high-quality solutions for users.
Main categories
1.Medical Device Assembly Machine
2.Drug Packaging Assembly Machine
3.Food Beverage Consumables Assembly Machine
4.Daily Use, Electronic&Metals Assembly Machine
5.General Machine
6.Cap Assembly Machine
7.Whole Solution Production Line
Equipment features
1.Customised turntable type or loop type production line according to customer's actual capacity.
2.The main power is composed of servo motor + reducer, doing intermittent motion.When assembling the products, the fixture is in a static state, precise assembling and high qualified rate.
3. Equipped with automatic detection function, each step of the assembly process is detected to achieve 100% qualified products.
4. All materials are made of stainless steel and aluminium alloy, in line with GMP requirements.
5. Equipped with automatic orientation function, avoiding the dead spot position between screw threads to ensure the correctness of assembly.
6. Torque detection step can be added.
7. According to the product structure, it can realise automatic pressing or automatic screwing.
8. Adopting vibrating disc to automatically sort out the direction of bottle cap, automatic feeding, automatic discharge to the workpiece;
9. Simple maintenance and easy operation.Low requirement for operator's professional level.Short replacement time for spare parts.
Properties
| Name |
Heli cap assembly machine |
| Production speed |
3000-13000pcs/h |
| Applicable products |
Carton milk cap, consisting of three spare parts that need to be orientated and screwed on the product |
| Rate of qualified product |
Above 98% |
| Dimension |
Actual size varied with production speed |
| Operator |
1set/person |
